Features

• Lightweight CF3 carbon fibre frame with 2.4" tyre clearance
• Progressive geometry with AGILOMETER sizing for confident handling
• Shimano XT 12-speed drivetrain for crisp shifting
• RockShox SID fork with 100 mm travel and remote lockout
• Carbon fibre seatpost for improved comfort

Specifications

• Intended Use- Mountain
• Wheel Size- 29"
• Braking System- Hydraulic Disc
• Frame Material- Carbon

Components

• Frame- BIG.NINE CF3 III material: carbon 29x2.4" max. wheelsize 148x12 mm axle standard BSA bottom bracket standard
• Fork- Rock Shox SID SL Air 100 mm suspension travel Tapered 2 position remote lockout 29x2.4" max. wheelsize 44 mm fork offset
• Chain- KMC X12
• Crank- Shimano XT 34 teeth 170 mm-S, 175 mm-M up
• Shift Levers- Shimano XT M8100 Multi Release
• Cassette- Shimano XT 10-51 teeth 12 speed
• Rear Derailleur- Shimano XT SGS
• Handlebar- MERIDA EXPERT CC material: aluminum 760 mm width flat
• Stem- MERIDA TEAM CC III material: aluminum 31.8 mm diameter -6° stem angle incl. MERIDA SMART MOUNT S, M: 60 mm, L, XL: 70 mm, XXL: 80 mm
• Saddle- MERIDA EXPERT SL V-mount incl. MERIDA minitool
• Seatpost- FSA SL-K material: carbon 30.9 mm diameter 0 mm setback size S and M: 400 mm size L, XL and XXL: 450 mm
• Front Brake- Shimano XT M8100 2 piston
• Rear Brake- Shimano XT M8100 2 piston
• Front Wheel- MERIDA EXPERT CC II 25 mm inner width material: aluminum Tubeless read ; Shimano XT 110x15 mm width front hub 32 spoke holes Centerlock
• Rear Wheel- MERIDA EXPERT CC II 25 mm inner width material: aluminum Tubeless read ; Shimano XT 148x12 mm width rear hub, 32 spoke holes Centerlock
• Tire- Maxxis Rekon Race 29x2.4" WT tubeless ready 3C MaxxTerra EXO
• Weight(Apprx)- M-10.4kg
